DC to DC CC-CV Boost Module 600 Watts

600 Watt DC-DC Step UP Boost Adjustable CC CV module with 12 volt to 80 volts variable output

This is a non isolated step up 600 watt high Power DC to DC boost module with wide input voltage range and with adjustable output voltage and adjustable output current. You can adjust the output voltage from 12 volts to 80 volts provided the input voltage is less than output voltage (This is a step up Boost module).

Check our complete range of DC to DC Step up and Step Down converter modules.

We have various types of Load Cells, Force Sensor, Flex Sensor and Pressure Sensor. Check our complete collection of Weigh Sensor and Load cell.

Specifications of 600 Watt DC to DC Boost Module

• Wattage: 600 watts
• Output Voltage: 12 - 80 Volts DC  (Variable)
• Input Voltage: 12 - 60 Volts DC
• Input current: 16 Ampere
• Constant current range: 0.2 - 12 Ampere
• Working temperature: -40~+85 degrees
• Working frequency: 150KHz
• Conversion efficiency: up to 95%
• Over current protection: input over 17 Ampere, automatically reduces output voltage
• Short circuit protection: input 20 Ampere fuse
• Module Size: 76mm x 60mm x 56mm

Application of 600 watt DC to DC boost Module

• DIY a regulated power supply, input 12V can be, output can be 12-80 Volts adjustable power supply for your electronic device, and you can set the output value according to your system voltage.
• As a vehicle power supply, for your laptop, PDA or all kinds of digital products powered.
• DIY a high-power mobile power notebook: with a large capacity of 12V lithium battery pack, let your notebook go where you can light up.
• Solar panels stabilize voltage to charge batteries or electric vehicles.
• Use low voltage batteries to charge high voltage batteries or lithium batteries.
• Drive high power LED lamp.

Package Includes:

• 1 x 600 Watt DC to DC 10-60 Volts to 12-80 Volts CC-CV Boost Module
