AT24C1024 Two-wire Serial EEPROM IC

AT24C1024 Two-wire Serial EEPROM IC

The AT24C1024 is a member of Atmel/Microchip's two-wire serial EEPROM family. It is designed for ease of use with low-power consumption and high reliability. It communicates via the I²C (Inter-Integrated Circuit) bus protocol, making it simple to interface with microcontrollers and processors. The IC provides a cost-effective and robust solution for storing data such as configuration settings, calibration data, and small-scale file systems.

DNA solutions, Nashik has various types of EEPROM IC's. Check out our complete collection of EEPROM IC's.

• Memory Organization: 1 Megabit capacity, organized as 131,072 x 8 bits

• Two-Wire Interface: Supports I²C-compatible communication

• Wide Operating Voltage Range: Operates from 1.7V to 5.5V

• Standard mode: up to 100 kHz

• Fast mode: up to 400 kHz

• Endurance: Up to 1 million write/erase cycles

Specifications of AT24C1024 Two-wire Serial EEPROM IC

• Capacity: 1 Mb (128 KB)

• Communication Protocol: Supporting 7-bit or 10-bit addressing

• Write Cycle Time: Maximum of 5 ms per page write

• Operating Temperature: -40°C to +85°C

• Packaging Options: 8-pin SOIC, TSSOP, DFN, and more

Applications of AT24C1024 Two-wire Serial EEPROM IC

• Consumer Electronics

• Embedded Systems

• Industrial Control

• Medical Devices

• IoT Devices

Package Includes

      1 x AT24C1024 Two-wire Serial EEPROM IC
