Meanwell RS-25-5 Power Supply

5 Volts, 25 Watt Single Output Switching Power Supply from Meanwell

RS-25-5 is a high quality Industrial Grade SMPS fom Meanwell. RS25-5 SMPS is a 15 watt SMPS and gives 12 volts output. Meanwell RS-25-5 switching power supply comes in mesh type casing and is very easy to mount.

Check out our Complete variety of Meanwell SMPS that we have.

We have various types of Load Cells, Force Sensor, Flex Sensor and Pressure Sensor. Check our complete collection of Weigh Sensor and Load cell.

Features of RS25-5 Meanwell SMPS

Protections : Short circuit / Overload / Over voltage / Over temperature

Universal AC input / Full range

Cooling by free air convection

LED indicator for power on

100% full load burn-in test

No load power consumption<0.5W

All using 105  long life electrolytic capacitors

Withstand 300 VAC surge input for 5 second

High operating temperature up to 70°C

Withstand 5G vibration test

High efficiency, long life and high reliability

Specification for RS25-5 Meanwell Power Supply

OUTPUT	Wattage  Voltage  Max Current	25 Watt 5 Volts 3 Ampere
INPUT	Efficiency Frequency Range:	78.5 % 47 ~ 63Hz
PROTECTION	Overloaded Over Volt	110 ~ 180% Rated Output Power. 5.75 ~6.75 Volts
ENVIRONMENT	Working Temp: Working Humidity: Storage Temp:  Vibration:	-20 ~ +70°C 20 ~ 90% RH non-condensing -40 ~ +85, 10 ~ 95% RH 10 ~ 500Hz, 5G 10min./1cycle, period for  60min. each along X, Y, Z axes
