MEANWELL SE-450-12 450W AC-DC Single-Output SMPS

MEANWELL SE-450-12 450W AC-DC Single-Output SMPS

The Mean Well SE-450-12 is a 12V/37.5A SMPS that converts AC mains voltage to a regulated DC output. With a universal AC input, the power supply can be used in different regions without the need for adjustments. It features a metal casing with built-in cooling to ensure optimal performance under continuous load conditions. The power supply also includes overload, overvoltage, and short-circuit protection, ensuring safe operation and protecting connected devices. The SE-450-12 operates efficiently, minimizing heat generation and power loss, which is crucial for systems requiring reliable power in demanding environments.

DNA solutions, Nashik has various types of Meanwell's. Check out our complete collection of Meanwell's.

• High Power Output: Provides up to 450W at 12V DC and 37.5A, suitable for high-power applications.


• Universal AC Input: Wide input voltage range from 90 to 132VAC / 180 to 264VAC (with selectable input by switch), or 254 to 370VDC, making it suitable for global use.


• High Efficiency: Operates at an efficiency of up to 83%, ensuring low power loss and heat generation.


• Active Cooling: Built-in DC fan for forced air cooling, allowing stable performance under full load.


• Adjustable Output Voltage: Fine-tune the output voltage between 10.8V and 13.2V for specific application requirements.


• Full Protection: Equipped with overload, overvoltage, and short-circuit protection for reliable and safe operation.


Specifications of MEANWELL SE-450-12 450W AC-DC Single-Output SMPS

• Input Voltage Range: 90 ~ 132VAC / 180 ~ 264VAC (selectable by switch)


• Output Voltage: 12V DC.


• Output Current: 37.5A.


• Power Output: 450W.


• Efficiency: 83%.


• Ripple & Noise: 150mVp-p.


• Voltage Adjustment Range: 10.8 ~ 13.2V.


• Overload Protection: 105% ~ 150% rated output power, constant current limiting, auto recovery.


Package Includes

• 1 x MEANWELL SE-450-12 450W AC-DC Single-Output SMPS
