SSG-5L2P Microswitch Snap Action SPDT 5A 125V

SSG-5L2P Microswitch Snap Action SPDT 5A 125V

The SSG-5L2P is a subminiature, snap-action, Single Pole Double Throw (SPDT) microswitch manufactured by Omron Electronics. It is specifically designed for applications that require reliable, fast-switching operations, handling moderate electrical loads with an efficient and compact form factor. Below is a detailed breakdown of its features, working principles, and applications.

DNA solutions, Nashik has various types of Switch's Check out our complete collection of Switch's

• Snap Action Mechanism Fast and Positive Switching: The snap-action mechanism ensures a very quick transition from one state to another.

• SPDT (Single Pole Double Throw) Configuration Versatile Switching: The SPDT configuration allows you to control two different circuits with a single actuator.

• Current Rating: 5A at 125V AC: Power Handling: The switch can handle a maximum current of 5A at 125V AC, making it suitable for controlling electrical circuits carrying moderate power levels.

• Roller Lever Smooth Actuation: The roller lever mechanism makes the switch more efficient in transferring motion to the internal mechanism.

Specifications of SSG-5L2P Microswitch Snap Action SPDT 5A 125V

• Actuation Type: Snap Action

• Switch Type: SPDT (Single Pole, Double Throw)

• Lever Type: Roller Lever


• Mounting Type: Solder Terminals

• Size: Subminiature

• Mechanical Life: Rated for millions of cycles

• Durability: Shock and vibration-resistant


Applications of SSG-5L2P Microswitch Snap Action SPDT 5A 125V

• Automated Control Systems

• Consumer Electronics

• Limit switches

• Security Systems

• Industrial machinery

• Medical Equipment

Package Includes

      1 x SSG-5L2P Microswitch Snap Action SPDT 5A 125V
