Waveshare UPS HAT (D) for Raspberry Pi

Waveshare UPS HAT (D) for Raspberry Pi Supports 21700 Li battery (NOT included) 5V Uninterruptible Power Supply Pogo Pins Connector

The UPS HAT (D) is an uninterruptible power supply (UPS) expansion board specially designed for the Raspberry Pi series. Onboard switching Li battery charging chip with path management, boost converter chip, and voltage/current monitoring chip. Supports simultaneous charging and discharging, and can provide stable 5V voltage output. Also, you can monitor the parameters via the I2C interface, such as the battery voltage, current, and power. Supports displaying the battery level on the system, easy to check the battery's remaining capacity.

DNA solutions, Nashik has various types of Waveshare's products. Check out our complete collection of Waveshare's products.

• Adopts pogo pins connector design, compatible with Raspberry Pi series boards.

• Onboard Li battery charging chip, with dynamic path management, a more stable power supply.

• Onboard boost converter chip for stable 5V power output.

• I2C bus communication, monitoring the battery voltage, current, power, and remaining capacity in real-time.

• Multi battery protection circuits: overcharge/discharge protection, over current protection, short circuit protection, more safe and stable.

• Onboard LED indicators for monitoring the battery operating status.

• Comes with online development resources and manuals.

Specifications of Waveshare UPS HAT (D) for Raspberry Pi

• OUTPUT VOLTAGE: 5V

• CONTROL BUS: I2C

• BATTERY SUPPORT: 21700 rechargeable Li battery 3.6V

• CHARGER SUPPORT: 5V, Type-C connector

• CURRENT CAPACITY: 5000mAh (Standard)

• DIMENSIONS: 56 × 85mm

• MOUNTING HOLE SIZE: 3.0mm

Package Includes

• 1 x Waveshare UPS HAT (D) for Raspberry Pi
• 1 x Acrylic protection panel
• 1 x Screws pack
